RM Italy MUA 100 Wideband UHF Amplifier – a compact 100 watt linear amplifier that covers the UHF frequency range from 405 to 480 MHz. This unit is ideally suited for use with low power handheld transceivers with an input drive range from 0.1 to 5 watts. The MUA 100 features include a high SWR protection circuit, a heatsink mounted fan for temperature control and an automatic RF sense relay. Even though a ground on transmit PTT cable to the provided relay phono connector is not required, it is recommended for SSB operations.

The MUA 100 power supply requirement is 12 to 16 Vdc to maximum continuous input current of 20A at full output. Unit dimensions (WHD) are 7.480 x 3.228 x 7.480 in. (190 x 82 x 190 mm) and weight is 3.3 lbs. (1.5 kg). Input and Output RF connectors are Type-N Female.

Expand the range of coverage for your handheld or low power base/portable UHF radio with the elegant 100 watts of the RM Italy MUA 100 Wideband UHF Amplifier.

Note: Amplifier Color may vary.
